Инструменты

Вот некоторые основные инструменты, используемые для работы на данном устройстве. Вам, возможно, не понадобиться каждый инструмент для каждой процедуры.

Troubleshooting

For additional help on the HP ENVY x360 m6-w 101dx, check out the device's troubleshooting page

Background and Identification

The HP Envy x360 m6-w101dx is a premium-class convertible notebook PC with a 15.6-inch Full HD touch screen mounted on a fully-rotatable hinge and Intel’s mid-range Core i5 processor.

The laptop has no DVD burner. There’s a full-size keyboard with backlight and numeric pad, a big trackpad, stereo speakers by Bang & Olufsen, webcam, 802.11AC Wi-Fi, Ethernet LAN, and Bluetooth connections, three USB ports, media card reader, HDMI video output, and a combo audio jack. HP’s Envy x360 m6-w101dx / m6-w010dx weighs in at 5.1 pound and is 0.9″ thick. It also updates the 5-generation core mobile processor and the NVIDIA geforce 940mx graphics card with 4GB video memory. The palm rest and lid have a silver-colored brushed metal finish, while the rest of the notebook is made of silver plastics.

The only difference between the m6-w 101dx and m6-w 010dx is in the software department. The m6-w 101dx comes with the latest Windows 10 OS, whereas the older m6-w010dx runs Windows 8.1 with free upgrade rights to Windows 10.

As the best selling point, the touch display features not only sharp 1920×1080 Full HD resolution, but also IPS technology for ultimately wide viewing angles. Computing is powered by the Core i5-5200U dual-core chip with the Intel HD 5500 integrated graphics. These, coupled with 8GB of system memory, provide seamless completion of the daily chores, a decent potential for heavier stuff like photo and video editing, entry-level gaming performance, and a plenty of multitasking headroom.

Source: Laptoping

Specifications

Product Number: M1V68UA

Microprocessor: 2.2GHz 5th generation Intel Core i5-5200U Dual Core

Microprocessor Cache: 3MB L3 Cache

Memory: 8GB DDR3L SDRAM (1 DIMM)

Video Graphics: Intel HD graphics 5500

Display: 15.6" diagonal Full HD IPS WLED-backlit touch screen (1920 x 1080)

Hard Drive: 1TB 5400RPM hard drive

Network Card: Integrated 10/100/1000 GbE LAN

Wireless Connectivity: 2x2 802.11ac WLAN and Bluetooth

Sound: Bang & Olufsen with dual speakers

Keyboard: Full-size backlit keyboard with numeric keypad

Pointing Device: HP Imagepad with multi-touch gesture support

External Ports

  • Multi-format digital media card reader
  • 2 SuperSpeed USB 3.0, 1 supporting USB Boost
  • 1 Universal Serial Bus (USB) 2.0
  • 1 HDMI
  • 1 RJ-45 (LAN)
  • 1 Headphone-out/microphone-in combo jack

Dimensions: 0.94in (H) x 15.04in (W) x 9.84in (D)

Weight: 5.06 lb

Power

  • 45W AC adapter
  • 3-cell 48WHr prismatic battery

ID Mech Description: Front facing HP TrueVision HD Webcam with integrated dual array digital microphone

Operating System: Windows 10 Home (64-bit)

Source: HP support

Additional Informations

HP Device Page

Laptoping Device page

Netbookcheck Review

Newegg Accessories and Parts
